Generating Container SBOMs in Jenkins

This guide adds an SBOM (Software Bill of Materials) stage to a Jenkins pipeline using the AccuKnox ASPM Scanner plugin. A CycloneDX SBOM is generated for a container image and uploaded to AccuKnox under a named project.

Prerequisites

• A Jenkins controller (2.387.3 LTS or newer) with at least one build agent.
• An AccuKnox SaaS account with a tenant / label you can upload findings to.
• Network egress from the Jenkins agent to the AccuKnox control plane (or a mirrored scanner image for air-gapped agents).
• An AccuKnox project pre-created with classifier container. The SBOM upload fails otherwise.

Pre-create the project on AccuKnox

The projectName you pass to accuknoxSbom must already exist on the AccuKnox console with classifier container. Without it, uploads are accepted but the back-end raises ValueError: Project '<name>' with classifier 'container' not found.

Step 1: Install the AccuKnox ASPM Plugin

See Installing the AccuKnox ASPM Jenkins Plugin for the one-time plugin installation steps.

Step 2: Configure Jenkins and pre-create the SBOM project

• Store the AccuKnox token as a Jenkins Secret text credential.
• Set the endpoint, label, and token credential on the global config.
• On the AccuKnox console, go to Projects → Add Project and create the project name you plan to pass as projectName, with classifier container.

Step 3: Define the Jenkins Pipeline

// AccuKnox SBOM generation, standalone Jenkinsfile.
//
// Generates a CycloneDX SBOM for a container image and uploads it to AccuKnox.
// PROJECT_NAME is what the SBOM is attached to in the AccuKnox UI.

pipeline {
  agent any

  parameters {
    string(name: 'IMAGE',
           defaultValue: 'nginx:1.27.1',
           description: 'Container image to generate SBOM for.')

    string(name: 'PROJECT_NAME',
           defaultValue: 'jenkins-sbom-demo',
           description: 'Project name to associate the SBOM with on AccuKnox.')

    booleanParam(name: 'SOFT_FAIL',
                 defaultValue: true,
                 description: 'SBOM has no per-finding severity; SOFT_FAIL=true is the sensible default.')

    booleanParam(name: 'CONTAINER_MODE',
                 defaultValue: false,
                 description: 'Run the scanner inside Docker (requires Docker on the agent).')
  }

  options {
    timestamps()
    timeout(time: 20, unit: 'MINUTES')
    disableConcurrentBuilds()
  }

  stages {
    stage('SBOM') {
      steps {
        accuknoxSbom(image: params.IMAGE,
                     projectName: params.PROJECT_NAME,
                     softFail: params.SOFT_FAIL,
                     containerMode: params.CONTAINER_MODE)
      }
    }
  }
}

Pipeline inputs

Step parametersCommon knobs

Parameter	Description	Required	Default
image	Container image reference.	yes	required
projectName	AccuKnox project (classifier container) to attach the SBOM to.	yes (or via global)	(global default)
softFail	SBOM has no per-finding severity; true is the sensible default.	no	true
containerMode	Run the scanner inside Docker on the agent.	no	false
scanImage	Air-gapped: mirrored scanner image to use.	no	(unset)

Every accuknox* step accepts these:

Parameter	Default	Notes
endpoint	from global config	Control-plane host (no scheme). Per-step override.
label	from global config	Becomes the label_id on the upload.
credentialsId	from global config	Jenkins credential ID holding the AccuKnox bearer token.
skipUpload	false	Run the scanner but don't upload. Useful for dry runs.
keepResults	true	Keep results JSON on the agent and archive it as a build artifact.
containerMode	false	Run the scanner inside Docker on the agent.
cliPath	auto	Path to a pre-staged accuknox-aspm-scanner binary (air-gapped use).

Without AccuKnox vs With AccuKnox

Without AccuKnoxWith AccuKnox

An SBOM JSON file is left on the agent. Asset inventory and vulnerability matching are someone else's problem.

The CycloneDX SBOM is shipped to AccuKnox and attached to the named project, where it powers asset inventory, supply-chain queries, and the runtime correlation views.

Figure 1. SBOM attached to a project on AccuKnox.

Viewing Results in AccuKnox

Once the Jenkins job uploads its SBOM, the project view is updated in the AccuKnox SaaS console.

1. Log in to the AccuKnox console and switch to the tenant whose label you configured in Jenkins.
2. Open Projects and pick the project name you passed as projectName.
3. Inspect the components, licenses, and supply-chain graph attached to the SBOM.
4. Cross-reference components with CVEs via the asset inventory.
5. Re-run the Jenkins job whenever the image is rebuilt. The latest SBOM replaces the previous one on the project.

Conclusion

Wiring SBOM generation into Jenkins via the AccuKnox ASPM plugin gives you continuous, automated supply-chain visibility on every build. Combine it with the other scan types (SAST, IaC, Secret, Container, SCA) to get full-coverage ASPM directly from your pipelines.
