IaC Scanning in Jenkins

This guide configures a Jenkins pipeline that scans Infrastructure-as-Code (Terraform, CloudFormation, Kubernetes manifests, Helm charts, ARM templates, Dockerfiles) using the AccuKnox ASPM Scanner plugin, with results auto-forwarded to AccuKnox.

Prerequisites

• A Jenkins controller (2.387.3 LTS or newer) with at least one build agent.
• An AccuKnox SaaS account with a tenant / label you can upload findings to.
• Network egress from the Jenkins agent to the AccuKnox control plane (or a mirrored scanner image for air-gapped agents).

Step 1: Install the AccuKnox ASPM Plugin

See Installing the AccuKnox ASPM Jenkins Plugin for the one-time plugin installation steps.

Step 2: Configure Jenkins credentials and global settings

• Add the AccuKnox token as a Jenkins Secret text credential.
• Under Manage Jenkins → System → AccuKnox ASPM, set the endpoint, label, and select the token credential.

Step 3: Define the Jenkins Pipeline

// AccuKnox IaC scan, standalone Jenkinsfile.
//
// Clones a repo, runs accuknoxIac inside it. Detects Terraform, CloudFormation,
// Kubernetes manifests, Helm charts, ARM templates, etc.

pipeline {
  agent any

  parameters {
    string(name: 'REPO_URL',
           defaultValue: 'https://github.com/Vickydew1/Testing.git',
           description: 'Git repo to clone and scan.')

    string(name: 'DIRECTORY',
           defaultValue: '.',
           description: 'Directory inside the repo to scan for IaC files.')

    string(name: 'SEVERITY_THRESHOLD',
           defaultValue: 'HIGH,CRITICAL',
           description: 'Comma-separated severities that fail the build.')

    booleanParam(name: 'SOFT_FAIL',
                 defaultValue: true,
                 description: 'true (default) = run and upload, build stays green; false = fail build on matching severities.')
  }

  options {
    timestamps()
    timeout(time: 20, unit: 'MINUTES')
    disableConcurrentBuilds()
  }

  environment {
    REPO_URL = "${params.REPO_URL}"
  }

  stages {
    stage('Checkout') {
      steps {
        sh '''
          set -eu
          rm -rf repo
          git clone --depth=1 "$REPO_URL" repo
        '''
      }
    }

    stage('IaC') {
      steps {
        dir('repo') {
          accuknoxIac(directory: params.DIRECTORY,
                      severityThreshold: params.SEVERITY_THRESHOLD,
                      softFail: params.SOFT_FAIL)
        }
      }
    }
  }
}

Pipeline inputs

Step parametersCommon knobs

Parameter	Description	Required	Default
directory	Path inside the workspace to scan.	no	.
severityThreshold	CSV of severities that fail the build.	no	HIGH,CRITICAL
softFail	true = advisory only; false = fail build on matching severities.	no	false
repoUrl / repoBranch	Pass-through metadata for the AccuKnox upload.	no	(unset)

Every accuknox* step accepts these:

Parameter	Default	Notes
endpoint	from global config	Control-plane host (no scheme). Per-step override.
label	from global config	Becomes the label_id on the upload.
credentialsId	from global config	Jenkins credential ID holding the AccuKnox bearer token.
skipUpload	false	Run the scanner but don't upload. Useful for dry runs.
keepResults	true	Keep results JSON on the agent and archive it as a build artifact.
containerMode	false	Run the scanner inside Docker on the agent.
cliPath	auto	Path to a pre-staged accuknox-aspm-scanner binary (air-gapped use).

Without AccuKnox vs With AccuKnox

Without AccuKnoxWith AccuKnox

Checkov or similar IaC scanners produce a JSON report locally; engineers must manually inspect or wire up dashboards to surface results.

The plugin forwards the IaC report to AccuKnox, where findings are tied to their files and resources, deduplicated across builds, and ticketable from the console.

Figure 1. IaC findings rendered in the AccuKnox console.

Viewing Results in AccuKnox

Once the Jenkins job uploads its report, the findings are available in the AccuKnox SaaS console.

1. Log in to the AccuKnox console and switch to the tenant whose label you configured in Jenkins.
2. Open Issues → Findings, and filter by the data type that matches the scan (SAST, IaC, Secret, Container, SBOM, SCA).
3. Click any finding to inspect the file, line, CWE, and the recommended remediation.
4. Use the ASK AI button on a finding for an LLM-generated explanation and patch suggestion.
5. Create a ticket directly from the finding to track remediation.
6. Re-run the Jenkins job after fixing the issue. The finding flips to Resolved on the next ingest.

Conclusion

Wiring IaC scanning into Jenkins via the AccuKnox ASPM plugin gives you continuous, automated detection of issues on every build, with a single pane of glass in the AccuKnox console for triage, ticketing, and verification. Combine it with the other scan types (SAST, Secret, Container, SBOM, SCA) to get full-coverage ASPM directly from your pipelines.
